Mobile interception head sampler

Product introduction

The DZC mobile bucket intercepting sampling machine is installed at the belt roller position, and the driving motor and the chain transmission mechanism drive the moving trolley, thereby driving the sampling hopper to realize the horizontal reciprocating motion between the initial position and the extreme position. When sampling, the intercepting trajectory is perpendicular to the flow plane, and a full width and full thickness subsample is taken from the stream.

Application areas: ports, steel, etc.
TECHNICAL PARAMETER
Adapting materialsiron ore, sinter, pellets, etc.
Adapt to Bandwidth500-2200mm
Sampling granularity10-200mm
Open size50-450mm
take a method1 full width and full thickness (weight interval/time interval)
Cutting knife material4Cr13 or SUS304
Intercept rate0.12-1.2m/s (frequency conversion adjustment)
Intercept speed deviation1<±5%
Quality variation coefficientCV<20%
Total weight about 5.5-5.7T
Power380V 50Hz
