Jaw Crusher
Product introduction
The DEP jaw crusher is suitable for crushing medium hardness ores or other brittle materials. It can be used as a pre-stage crushing of ore and brittle materials as various types of real (chemical) laboratories, and is prepared for the middle and fine crushing of lower grades. It is especially suitable as a pre-stage crushing of various experimental crushers.
The body is cast from cast steel at a time, and the structure of each part is reasonable and the design is perfect.
TECHNICAL PARAMETER
| Adapting materials | Iron ore, sinter, pellets, coke, coal, etc. | ||
|---|---|---|---|
| feed port size | 400×250mm | 250×200mm | 180×100mm |
| Maximum feed size | ≤150mm | ≤100mm | ≤80mm |
| Processing amount | 4t | 3t/h | 1t/h |
| Discharge port adjustment range | 20-50mm | 10-35mm | 5-25mm |
| Crushing efficiency | ≥95% | ≥95% | ≥95% |
| Adapt to moisture | ≤15% | ≤15% | ≤15% |
| Power | 15kw | 7.5kw | 5.5kw |
| Power | 380V 50Hz | 380V 50Hz | 380V 50Hz |
Technical features
The speed is low and the operation is stable.
The fascia is made of special materials, compact, durable and easy to adjust.
The discharge particle size is uniform.
The whole seal has a good sealing property to prevent the fine mineral powder and water from being lost, and the rotating part has a safety cover.
The fascia is made of special materials, compact, durable and easy to adjust.
The discharge particle size is uniform.
The whole seal has a good sealing property to prevent the fine mineral powder and water from being lost, and the rotating part has a safety cover.
