Single bucket elevator

Product introduction

DDT type single bucket hoist is designed and manufactured according to the characteristics of domestic and foreign hoist and combined with the actual situation of the sample preparation system. It is mainly used for material lifting in ore mining systems such as ore, sinter, and coke. It is especially suitable for lifting materials with large particle size.
The DDT single bucket hoist has the characteristics of accurate lifting position, stable operation, safety and flexibility.

Applications: Ports, steel, electricity, coal, chemicals, etc.
TECHNICAL PARAMETER
Adapting materials iron ore, sinter, pellets, coke, coal
form Bullet cable traction type
Maximum bucket capacity 500kg
Bag material SUS304
Travel 2-30m
Raise speed 0.12m/s
Wire rope diameter 16mm
Power 5.5kw
Power 380V 50Hz
